| Type |
Rated Load (kg) |
Tare weight(kg) |
Dimensions(mm) |
| 40ft terminal trailer |
45000 |
6800KG |
13000*2770*1783mm |
| 45ft terminal trailer |
65000 |
8000KG |
14103*2770*1783mm |
| Wheel Base (mm) |
1310 |
| Axle |
16/18 /20T FUWA / BPW or Factory Brand |
| Tire & Rim |
12R22.5 1100R20 1200R20 & 9.0-22.5 8.0-20 9.0-20 |
| Suspension |
Heavy Duty Mechanic Suspension with Leaf Springs |
| leaf-spring Pcs |
10 |
| Kingpin |
2′ or 3.5′ Interchangeable |
| Landing gear |
28T loading capacity with 80T static lifting capacity. |
| Platform |
Skeletal Chassis Loading Deck |
| Main Beam Material |
Q345B manganese plates, automatic submerged arc welded |
| Main Beam Size |
Upper plate thickness |
16mm |
| Lower plate thickness |
18mm |
| Mid Web thickness |
10 mm |
| Height |
500-520mm |
| Brake System |
Double air chamber ,brake valve WABCO Brand ,40L air tanks;ABS optional |
| Electrical System |
24V, 7core socket, lights according to European standards. |
| Tool Box |
1 box of standard tools |
| Spare tire carrier |
2 sets |
| Color and Logo |
Depends on the buyer’s requirement. |
| Pin Height |
According to the height of the tractor saddle. |
| Painting |
Three coats painting; Any color will be ok |
| Other Specifications |
The frame can be flat plate style and skeleton style.Twist lock settings installed 12 pics, 8 pics, and 4pcs to satisfy the containers with different sizes for convince. |
| Application |
For 2x20ft 1x40ft or 1x45ft containers transport |
